Details of Portable and Silent Diesel Generator

Oct. 15, 2019


GT series automobile power station is to install the generator on a mobile site, which has a strong flexibility and adaptability.It’s suitable for rescue, emergency power supply or construction and power supply in remote areas. GFD series low noise power stations are divided into tank type and vehicular type, whose noise level can reach below 80 decibels (dba), so they are suitable for densely populated areas or sites which have strict request for environmental noise. These kinds of power stations offers good mobility, strong adaptability and quick power supply. they are widely used in the film and television production or municipal engineering construction.


Details of Portable and Silent Diesel Generator


Portable generator sets are innovative in design, and in addition the static tank, they also have the following merits:


1. Plate spring suspension structure; equipped with mechanical parking brake (hand brake) and air brake brake to transfer with the tractor;


2. The trailer adopts the height-adjustable bolt-type traction frame, which is suitable for all kinds of tractor, with a large turning angle and a high mobility.

Parameters of various models of portable generator are as follows:



Output (KW)

Diesel Engine

Wheel quantity (single shaft)

Wheel quantity (double shafts)

Wheel gap

Shaft

gap

Tyre Spec.

 Size

L×W×H(mm)

Weight(kg)

24

495D

2

 4

1450


550-13

3100×1500×1650

1600

30

4100D

2

 4

1450


550-13

3100×1500×1750

1750

40

R4105D

2

 4

1450

1800

550-13

2950×1950×1800

2000

50

4105ZD

2

4

1450

1800

550-13

2950×1950×1800

2600

75

6135D-3

 2

4

1450

2100

750

3400×1950×2300

3300

90

6135AD

 2

4

1450

2100

750

3400×1950×2300

3500

100

6105AZLD

 2

4

1450

2100

750

3400×1950×2300

2600

120

6135JZD

 2

4

1450

2100

750

3600×1950×2300

3800

150

6135AZD

 2

4

1450

2100

750

3600×1950×2300

4500

160

G128ZLD

 2

4

1700

2100

850

3600×1950×2300

4300

200

G128ZLD2

 2

4

1700

2100

850

3800×1950×2600

4900

250

G128ZLD1

 2

4

1700

2100

850

3800×1950×2600

5000

300

12V135AZD

 2

4

1700

2100

850

4000×2180×2600

5200


Learn Information about Low noise generator

Advantages of Low Noise Generator:


Low noise diesel gensets (silent generator) use technical measures of noise reduction such as shock isolation, sound attenuation, sound insulatio and sound-absorbing, which lead to a big reduction in the index of the noise. GFD series low noise power stations are divided into tank type and vehicular type, whose noise level can reach below 80 decibels (dba), so they are suitable for densely populated areas or sites which have strict request for environmental noise. These kinds of power stations offers good mobility, strong adaptability and quick power supply. they are widely used in the film and television production or municipal engineering construction.

Low Noise Generator Introduction

Low noise diesel generator sets are new series generator products which are developed by introducing and absorbing advanced foreign technology of low noise generator sets. The products comply with national standards GB/T2820-1997 or GB12786-91 and have been put into the market.This series of diesel gensets have significant performance of low noise. The multi-layer shielding impedance mismatch type sound insulation cover reduces the effects of noises on users. Large capacity oil burner, specially designed quick open cover, convenient maintenance, etc.

Application Scope:

The densely populated urban area, high-grade offices, star hotels, scientific research institutions, hospitals and universities and colleges, etc.


Characteristics of low noise generators:


1. Low noise, overall compact organization and small space occupation;


2. The tank body all is detachable-type structure, and it is put together with steel plates, the surface is coated with high-performance anti corrosive paint and it has the function of noise reduction and rainproof at the same time;


3. The internal part of the tank adopts multi-layer barrier impedance mismatch type structure and built-in large impedance muffler.


4. The tank structure design is reasonable, the internal part of the tank is equipped with large capacity fuel tank; equipped with two access doors at left and right sides at the same time, so as to facilitate the troubleshooting;


5. At the same time, the tank body is set up with a observing window and fault emergency stop button, in order to observe the running situation of the set and stop the set as soon as possible to avoid damaged unit once there is an emergency.



 We supply portable trailer generator set with power range from 20KW to 500KW.


portable trailer generator


Portable Trailer Diesel Generator



We supply mounted portable trailer generator sets with power range from 20KW to 800KW.


mounted portable trailer diesel generator



Mounted Portable Trailer Diesel Generator
