Introduction of Cummins Diesel Generator Set Control Panel

Aug. 02, 2023

The main purpose of the Cummins diesel generator set control panel is to distribute the electrical energy output by the generator to the user's load or electrical equipment, and also to indicate the operation of the Cummins diesel generator set and maintain the generator's voltage stability under load changes.

deutz hatz cummins perkins volvo

The control panel is generally equipped with a voltmeter, a frequency meter, an ammeter, a power meter, a three-phase current transfer switch, a three-phase voltage transfer switch, a voltage setting knob and various indicator lights. For components such as oil pressure gauge, oil temperature gauge, battery charging ammeter, water temperature gauge, start button and starter electric lock, some are directly installed on the control panel panel according to the design requirements, and some are installed on the diesel engine instrument panel. The components installed inside the control panel are mainly related to the excitation mode adopted by the generator and the automatic control of the diesel engine. The internal structure of the Cummins diesel generator set control panel.

Simple control panels are generally equipped with voltage regulators, silicon rectifier diodes, varistors, automatic air switches and current transformers. Silicon control, relays, various fuses and small transformers and other electrical equipment.

Dingbo Power was founded in 2006 and is one of the earliest manufacturers of generators and diesel generator sets in China. If you want get more information, please feel free to send email to sales@dieselgeneratortech.com we will pay highly attention on your question.
