Dingbo Sold 800KW Cummins Diesel Generator Set (KTA38-G5)

Aug. 07, 2023

Recently, a mining development company purchased one unit of 800kw Cummins diesel generator set from our company. Thanks for client’s cooperation, we will provide best product and service to you.


Our diesel generators have always been popular with customers at home and abroad, especially diesel generators powered by Cummins engine. Our Cummins genset power range is from 20kw to 2400kw, 50Hz/60Hz are available.


The 800KW diesel generator set purchased by the user is equipped with Cummins engine. Cummins diesel engine has the advantages of small volume, light weight, low fuel consumption, stronger power, reliable operation, convenient supply and maintenance of accessories. We are the OEM supplier of Cummins engine, having better performance, better quality and more guaranteed service in similar products.

cummins volvo perkins Diesel Generator 100-2500 kVA

Technical specifications for 800kw diesel generator set

Manufacturer: Dingbo Power

Genset model: DB-800GF (Open type)

Prime power: 800kw/1000kva

Standby power: 880kw/1100kva

Rated current: 1440A

Rated voltage: 230/400V

Rated frequency: 50Hz

Rated speed: 1500rpm

Overall size: 4500×2000×2300mm

Net weight: 6900KG

The genset includes automatic monitor system, muffler, shock absorber, maintenance-free 24V DC battery, user manual, maintenance & repair manual, factory test report etc.


Technical specifications for Cummins engine KTA38-G5 for 800kw genset

Manufacturer: Chongqing Cummins engine Co., Ltd

Engine model: KTA38-G5

Prime power: 881KW

Standby power: 970KW

Aspiration: Turbocharged, Aftercooled

Bore x Stroke: 159X159mm

Rated speed: 50Hz

No. of cylinder: 12

Type: 4 Cycle , 60° Vee

Capacity of engine oil: 135L

Fuel system: Cummins PT fuel pump

Displacement: 38L

Compress Ratio: 13.9:1

Fuel consumption( rated prime load) : 100%: 202g/KW.h, 75%: 207g/KW.h  50%: 194g/KW.h


Technical specifications for alternator for 800kw genset

Manufacturer: Shanghai Kepu

Model: TFW2-800

Capacity: 800kw/1000kva ( can over load 10% for 1 hour every 12 hours)

Type: Brushless self excitation, single bearing( options: two bearings)

Voltage regulation: AVR

Insulation class: H

Protection level: IP22

Alternator options: original Stamford, copy Stamford, Leroy Somer, ENGGA, Siemens, Marathon, Dingbo.


Technical specifications for controller for 800kw genset

Manufacturer: SmartGen

Model: 6110CAN

Electronic control with standard equipment and provides total generator set system integration,including auto remote start/stop, alarm and status message display.

Control panel options: Deep Sea


Above information is required by the customer. Of course, we also have other different specifications with different requirements if you need. If you have plan to purchase diesel generators this year, welcome to send inquiry to us by email sales@dieselgeneratortech.com, or call us by office phone number +8613481024441 ( same as WeChat No.).
