Disassembly Guidelines for Shanghai Qianneng 200KW Diesel Generator Sets

Shanghai Qianneng generator sets offer users a wide range of options, featuring compact size, light weight, low fuel consumption, high power output, reliable operation, and convenient access to spare parts and maintenance services. Equipped with an electronic governor, they include protection functions such as automatic shutdown triggered by high cooling water temperature, low oil pressure, and overspeed warnings.

200KW Shanghai Qianneng Generator Set

In practical operation, diesel generator maintenance requires extreme caution. Slight negligence can easily lead to starting failures, and troubleshooting can be highly complex. Therefore, attention to details in daily work is crucial to prevent accidents and ensure smooth disassembly. Dingbo Power shares the following disassembly principles:

Disassembly Principles for Shanghai Qianneng Generator Sets

1.Drain all fuel (diesel or gasoline), engine oil, and cooling water completely.

2.Adhere to the sequence: external components first, then internal ones; accessories first, then the main body; connecting parts first, then individual components; assemblies first, then sub-assemblies, combinations, and parts.

Disassembly Precautions for Shanghai Qianneng Diesel Generator Sets

Do not forcefully disassemble non-removable parts; understand the specific structure of the component first.

Avoid unnecessarily expanding the disassembly scope; determine the extent based on repair requirements and items. As recommended by the manufacturer Guangxi Dingbo Power, disassemble only when necessary.

Place removed parts in an organized manner; do not pile them randomly. Parts that cannot be repaired promptly should undergo rust-proof treatment.

Precision mating parts must be stored in pairs.

1.Cooling Requirement: Disassembly must be performed only when the machine is completely cooled. Otherwise, thermal stress may cause permanent deformation of components such as the cylinder block and cylinder head, affecting internal combustion engine performance.

2.Bolt/Nut Removal Sequence: When loosening bolts or nuts on components like cylinder heads, connecting rod bearing caps, and main bearing caps, follow a symmetrical and uniform sequence, loosening in 2–3 stages. Never loosen all nuts/bolts on one side first, as uneven force may cause deformation or cracking.

3.Marking Verification: Carefully mark components such as timing gears, pistons, connecting rods, bearings, valves, and adjustment shims. Note existing marks or create new ones on visible non-working surfaces without damaging assembly reference planes, preserving the original assembly relationships. For parts like wire connectors between the engine and generator, use paint, engraving, or tags for labeling.

4.Tool Usage and Force Control: Avoid excessive hammering; use appropriate tools, especially special tools. For example, use piston ring pliers to remove pistons and spark plug sockets for spark plugs, applying moderate force to prevent hand injuries and component damage.
