Diesel Generator Set Frequency Related Knowledge and Troubleshooting

In essence, the difference between 50Hz and 60Hz diesel generator sets is not significant, except for a slight difference in the rotational speed of the generator. Within a country (except Japan), the choice between 50Hz and 60Hz must be consistent. Frequency is a very important basic element in the power system and is not determined arbitrarily. A power system can only have one frequency. The rated frequency of the power systems in China and most European countries in the world is 50Hz, while most countries in the Americas use 60Hz.

The difference between 50Hz and 60Hz lies in that the determination of frequency is related to the structure and materials of generators, motors, transformers and other equipment.

If a 50Hz power supply is used for a production line requiring 60Hz, the speed of the AC motor will decrease (the motor speed is proportional to the frequency), causing the motor to heat up, and it will definitely burn out if it works for a long time. For contactors dedicated to 60Hz, when switched to 50Hz, they are prone to false tripping.

A 50Hz diesel generator set can be converted to 60Hz by increasing the rotational speed by 1.2 times, and the voltage will also increase by 1.2 times. The normal rotational speed of a 50Hz diesel generator set is 1500r/min, while that of a 60Hz diesel generator set is 1800r/min.

Reasons Why Diesel Generators Fail to Reach 50Hz

1.The power machinery (diesel engine, gasoline engine, etc.) has reached 1500 revolutions per minute, but the pulley ratio is not 1:1, which means that the generator speed does not reach 1500 revolutions per minute. If the speed is too low, the frequency will decrease. Only when the generator of Dingbo Power reaches the rated speed can it output the rated frequency and rated voltage.

2.The frequency meter is inaccurate or damaged. You can use a multimeter that supports frequency measurement to measure the actual AC frequency generated by the generator, or try replacing it with a new frequency meter of the same model.

You can increase the rotational speed further. The actual output voltage of a 380V generator is around 400V (including the output voltage of a 380V transformer). The voltage will drop during long-distance wire transmission.

There are no fake, shoddy, substandard or crudely made diesel generators in Dingbo Power. Every diesel generator set we produce is genuine and of high quality. Our company has been producing and selling diesel generators for 14 years, with exquisite craftsmanship and advanced testing methods, allowing you to buy with confidence and use with peace of mind. From pre-sales consultation, in-sales production and design to after-sales three-guarantee service, all services are provided by professional personnel. Welcome to consult us.

Fault Analysis of Low Voltage Frequency or Zero Indication of Diesel Generator Sets

This kind of fault seems to be caused by internal faults in the generator or its control part, but in fact, it is caused by the diesel engine's fuel supply system or mechanical faults that prevent the diesel engine from reaching the rated speed, resulting in the power generation frequency failing to reach 50Hz.

Causes of Low Voltage Frequency Fault in Diesel Generator Sets

1.One or more cylinders of the diesel engine are not working properly or not working at all.

2.The low-pressure oil circuit is partially blocked.

3.The fuel supply of the high-pressure oil pump does not meet the specified requirements of the machine, or some plungers inside the high-pressure oil pump are stuck.

4. There is air in the oil circuit.

5. The connecting rod bolts of the overhauled diesel engine are tightened too tightly, causing the connecting rod bearing and the journal to be too tightly combined.

6. The fuel transfer pump is not working properly.

7. Some fuel injectors are not injecting fuel.
