Diesel Generator Engine Cylinder Arrangements

As we all know, the engine is the power unit of a diesel generator set, and the performance of the engine directly affects the performance of the unit. There are many types of engines with different structures to meet the needs of different power requirements. When classified by the cylinder arrangement of diesel generator engines, they can be divided into in-line (L) and V-type, etc. A cylinder is a cylindrical chamber in the engine, inside which there is a piston pushed by the pressure or expansion force of the working fluid. Some special engines have similar but non-cylindrical parts.

V-type engine: All cylinders are divided into two groups, and adjacent cylinders are arranged at a certain angle, so that the two groups of cylinders form a plane with an included angle, and the cylinders a V-shape when viewed from the side. The V-type engine of Guangxi Dingbo Power has small height and length dimensions and stable operation. It is convenient to increase displacement and power by expanding the cylinder diameter and is suitable for a higher number of cylinders. At present, many domestic diesel generator sets adopt V-type 12-cylinder and 16-cylinder engines, such as Yuchai 12VC and 16VC series, which are both V-type engines. Disadvantages: The structure is relatively complex, which is not conducive to maintenance and repair, and the cost is relatively high.

In-line engine: In-line is currently the oldest and most widely used cylinder arrangement form. All its cylinders are arranged side by side in a single plane, usually 4-cylinder or 6-cylinder. Its cylinder block and crankshaft have a simple structure, and a single cylinder head is used, resulting in low manufacturing cost, high stability, good low-speed torque characteristics, low fuel consumption, and compact size, so it is widely used. Its disadvantage is relatively low power. When the displacement and the number of cylinders increase, the length of the engine will increase significantly. At present, the number of cylinders of mainstream in-line engines ranges from single-cylinder to 6-cylinder.
