Selection Requirements of Military Standby Diesel Generator Sets

Nowadays, diesel generator sets are widely used in various fields due to their superior performance and economy, such as military, real estate, schools, hospitals, fire protection, etc. However, different industries have different requirements for the configuration, design and selection of generator sets. Today, Dingbo Power will focus on discussing the design and selection requirements of military standby diesel generator sets with you.

1.Supporting Selection of Generator Sets

The selection of generator sets operating under special conditions is particularly important. When selecting, it is necessary to consider the application range of diesel engines. For example, generator sets must have the advantages of small size, light weight, good starting performance, and large power reserve to meet the needs of special conditions. Therefore, Dingbo Power Generator Manufacturer recommends you to choose the air-cooled diesel engine produced under the license patent of Deutz AG. This kind of diesel engine is equipped with a full-range mechanical governor, which has good stability, strong plateau adaptability, safe and reliable operation, and a major overhaul period of not less than 1000 hours. Especially, the air-cooled diesel engine has very superior low-temperature starting performance, and can start smoothly at an ambient temperature of -25 ℃ without other heating measures. Therefore, choosing Deutz air-cooled diesel generator sets for military use is the best choice.

2.Connection of Diesel Generator Sets

After selecting the diesel engine and generator, in order to reliably connect the two, an elastic connection method is needed. The diesel engine flywheel housing spigot is directly connected with the generator front end cover spigot, the diesel engine flywheel and the generator half-coupling are connected through a quadrangular frustum-shaped pin, and the feet are seated on the chassis through a two-way shock absorber.

3.Measures to Ensure Reliable Start of Diesel Engine at Low Temperature

Air-cooled diesel engines can start smoothly at a temperature lower than -25 ℃. But sometimes the ambient temperature will be lower than -25 ℃, even down to -40 ℃. In order to enable the generator set to start smoothly in a short time at lower temperatures, in the design of the generator set, in addition to using winter fuel and lubricating oil, we also use a heater to increase the intake air temperature to ensure the quick start of the generator.

4.Monitoring and Protection of Diesel Generator Sets

In order to ensure the stable operation of the generator set, it is necessary to monitor and protect the diesel engine and generator. The monitoring items of the diesel engine mainly include speed, oil temperature, oil pressure, cylinder temperature, fuel tank oil level, cumulative running time, battery charging, etc. The monitoring of generator output mainly includes current, frequency, voltage, insulation monitoring, etc.

In addition to the above measures to improve the reliability of diesel generator sets, other measures have also been taken, such as the speed control system set up for the rational use of diesel engines. The Deutz air-cooled diesel generator sets produced by Guangxi Dingbo Power have performance indicators that meet and exceed the requirements of technical conditions, and the stability of the products is guaranteed. They are high-quality choices for military standby and emergency power supply equipment. Welcome to contact us via [email protected] for business.
