Select a Single Cylinder Direct Injection Energy Saving Diesel Engine

Single-cylinder direct-injection energy-saving diesel engines, compared to traditional swirl-type models, feature rolling main bearings, uniquely shaped combustion chambers, and multi-hole injectors that directly spray fuel into the piston crown. These design improvements deliver advantages such as fuel/water efficiency, easy starting, and high power, making them increasingly popular for agricultural machinery. Here’s how to choose one that meets your needs:

1. Select Based on Requirements

With multiple manufacturers offering diverse models, choose based on your machinery’s power specifications. Check the nameplate for model, rated power, and rated speed to avoid mismatches (e.g., "overpowered" or "underpowered" engines) that cause waste or performance issues.

2. Visual Inspection

Cast Components (e.g., engine block): Should have smooth surfaces with no cracks or burrs.

Sheet Metal Parts (e.g., fuel tank): Should be flat, smooth, and free of dents, scratches, or paint defects.

Critical Check: Ensure no oil leaks on any engine surface.

3. Static Inspection

Crankshaft Rotation: With the throttle in the "stop" position and decompression engaged, turn the flywheel by hand—it should rotate smoothly without jamming or abnormal noises.

Compression Test: Release the decompression lever and rotate the flywheel. No air leakage should be heard from the intake/exhaust ports. If the flywheel does not reverse slightly when released before top dead center (TDC), compression is insufficient, indicating poor power/economy.

Oil Pressure: After decompression, rapidly crank the engine—the red indicator in the oil pressure gauge should rise, confirming proper lubrication.

Flywheel Play: Push/pull the flywheel axially/longitudinally; no excessive clearance should be felt.

Fuel Injection: With the throttle in the "on" position and decompression engaged, rapid flywheel rotation should produce a clear, crisp injection sound, indicating a functional fuel system.

4. Dynamic Inspection

Starting Performance: Fill with diesel, oil, and coolant. Hand-crank starting should succeed ≥75% of the time.

Throttle Response: Accelerate/decelerate smoothly with no lag. At minimum idle speed (<300 RPM), the engine should run steadily with no speed fluctuations ("hunting").

Exhaust Smoke: Should be light gray or colorless at all speeds; black, blue, or white smoke indicates problems.

Engine Sound: Should be steady, rhythmic, and free of metallic knocking or unusual noises.

Leakage Check: After running, inspect for oil, air, or water leaks at pipe joints, oil seals, gaskets, and drain valves.
