Technical Specification of 12M33D1210E200 Weifang Diesel Engine

As the primary base for Baudouin International Engine Company to enter the Chinese engine market, Baudouin (Weifang) Power Co., Ltd. has established a complete procurement system, advanced manufacturing facilities, and high - quality after - sales service in China. The company has passed certifications such as the GB/T19001 - 2008 Quality Management System, GB/T24001 - 2004 Environmental Management System, and GB/T28001 - 2011 Occupational Health and Safety Management System. Baudouin (Weifang) Power Co., Ltd. is committed to exploring the high - speed, high - power engine market in China and even East Asia.

Operating Environment of the 12M33D1210E200 Weifang Diesel Engine

1.The 12M33D1210E200 land - based power generation Weifang diesel engine should be able to output its rated power under the following conditions:

a) Absolute atmospheric pressure, PX: 100 kPa (or altitude: 0 meters);

b) Ambient temperature, Tr: 298 K (25°C);

c) Relative air humidity, Φr: 30%.

2.The diesel engine should be able to operate continuously and reliably under the following conditions:

a) Ambient temperature: The lower limit is - 10°C, and the upper limit is 50°C;

b) Relative air humidity: The average maximum relative humidity of the wettest month is 90% (when the monthly average minimum temperature of that month is 25°C).

d) There should be no explosive gases or conductive dust in the working environment.

e) If there are any special hazardous conditions at the work site (such as explosive atmospheric environment and flammable gases), the user should provide prior notice.

Curves of Fuel Consumption and Fuel Consumption Rate vs. Engine Power

Curve of fuel consumption varying with engine power

Curve of fuel consumption rate varying with engine power

Main Technical Parameters of the 12M33D1210E200 Weifang Diesel Engine

Diesel engine model: 12M33D1210E200

Diesel engine type: V - type, 4 - stroke, water - cooled, turbo - charged and inter - cooled

Number of cylinders/Number of valves: 12/48

Bore/stroke: 150 mm/185 mm

Compression ratio: 15:1

Displacement: 39.2 L

Rated power: 1100 kW

Overload power: 1210 kW

Rated speed: 1500 r/min

Idle speed: 750 ± 30 r/min

Firing order: 1 - 8 - 5 - 10 - 3 - 7 - 6 - 11 - 2 - 9 - 4 - 12

Crankshaft rotation direction: Counter - clockwise (viewed from the flywheel end)

Starting method: DC24V electric start

Starter power/voltage: 9 kW/24V

Speed regulation method: Electronic speed regulation

Cooling method: Water - cooled

Minimum allowable coolant temperature for engine body operation: 50°C

Coolant capacity of the engine itself: 75.94 L

Oil pan capacity: 146 L (subject to the oil dipstick)

Net weight of the engine (kg): 3390

Overall dimensions (length × width × height) (mm): 2524 x 1311 x 1731
