Structure and Wiring Methods of Three-Phase Alternator

The following content provides an overview of the components and wiring configurations of a three-phase alternator:

Components of a Three-Phase Alternator

A three-phase alternator typically consists of components such as the stator, rotor, end covers, brushes, frame, and bearings. The stator is composed of the frame, stator core, winding coils, and other structural parts that fix these components. The rotor includes the rotor core, rotor magnetic poles (with magnetic yoke and pole windings), slip rings (also known as copper rings or collector rings), fan, and rotating shaft.

Wiring Methods of Three-Phase Alternator

Three-phase motors have three wiring operation modes:

1.Star (Y) Connection: The start or end terminals of the three-phase stator windings inside the motor are connected together, and the other three ends are respectively connected to U, V, W three-phase AC power supply. This method is suitable for three-phase asynchronous induction motors of 3kW and below.

2.Delta (△) Connection: The start and end terminals of the three-phase stator windings are connected correspondingly. The start terminal of one phase winding connected to the end terminal of the third phase winding can be regarded as phase U, the start terminal of the second winding connected to the end terminal of the first winding as phase V, and the start terminal of the third winding connected to the end terminal of the second winding as phase W. These are respectively connected to U, V, W three-phase AC power supply. This method is applicable to three-phase asynchronous induction motors of 4kW and above. However, the wiring method of the motor should be based on the actual nameplate wiring.

Generally, there are six terminal posts on the terminal block of a three-phase AC motor. When the motor nameplate indicates a star connection, D6, D4, and D5 are connected together, and the remaining D1, D2, D3 are connected to the power supply. When it is a delta connection, D6 is connected to D1, D4 to D2, D5 to D1, and then D1, D2, D3 are connected to the power supply.

2.Direct Connection Power Supply Method: This method uses two wires for each phase of the AC voltage output by the three groups of coils of the generator to supply power to the users. This power supply method requires a total of six power supply wires. If the power supply distance is relatively long, this method is not advisable because the power supply cost is very high.

4.Delta Connection Power Supply: The start and end terminals of the three groups of coils of the generator are connected in sequence, forming a triangular connection. A wire (U phase line, V phase line, W phase line) is led out from each of the three connection points and connected to the users as shown in the figure. The voltage on the three groups of coils is respectively provided to their respective users. In this power supply method, the three groups of generator coils are connected in a triangle and three wires are used to transmit three-phase voltage, so it is called the three-phase three-wire delta connection power supply method.
