Heat Generation and Losses in Hydro Generators

No matter what kind of mechanical equipment is started and put into operation, it will generate heat, and hydro - generators are no exception. Synchronous generators are divided into three types according to the prime movers used: steam - turbine generators, hydro - generators, and diesel generators. A hydro - generator is a generator that uses a water turbine as the prime mover to convert water energy into electrical energy. When water flows through the water turbine, water energy is converted into mechanical energy. The rotating shaft of the water turbine then drives the rotor of the generator, converting mechanical energy into electrical energy for output.

The mechanical power obtained by a hydro - generator from the water turbine cannot all be converted into electrical power for output. There is always a certain amount of internal loss in the hydro - generator, mainly including four parts: iron loss, copper loss, mechanical loss, and additional loss. These losses can reduce the efficiency by 1% - 2%. For a 3000kW hydro - generator, it means a power loss of 30 - 60kW, and this loss causes the hydro - generator to generate heat.

(1)Iron loss refers to the hysteresis loss and eddy - current loss in the stator core.

(2) Copper loss includes the power loss generated when there is current in the stator winding and the excitation winding.

(3) Mechanical loss includes the friction loss of bearings and brushes, as well as the ventilation and wind - friction loss.

(4) Additional loss mainly includes the additional copper loss caused by the skin effect of the current in the stator winding, the pulsation loss caused by teeth and slots, and the iron loss generated on the surfaces of the stator and rotor by high - order harmonic magnetic fluxes.
