Common Causes of Low Voltage in 10kW Small Diesel Generators

Many customers have called asking why the voltage of the 10kW small diesel generators purchased from us is always below 220 volts.

In fact, small diesel generators are driven by a pulley, and their speed should be 2200 rpm. To save fuel, many users have unauthorizedly increased the diameter of the pulley. They want to reduce the speed of the diesel engine to save fuel. However, this has resulted in the generator speed failing to reach 2200 rpm, and its voltage will certainly not reach 220 volts. Therefore, its parameters cannot be adjusted arbitrarily.

Therefore, Dingbo Power Generator Manufacturer reminds you that our generator sets have undergone strict testing in the factory, and all parameters of the diesel engine and generator have been set. All generators have a rated speed of 2200 rpm and a rated voltage of 220V/380V. Multi-cylinder diesel generator sets have rated speeds of 1500 rpm and 1800 rpm, with rated voltages of 220V/380V and 110V/440V respectively. Do not arbitrarily change the factory settings, as this will affect the use of the diesel generator set and also affect the warranty of the diesel generator set. If there are any changes, please feel free to consult the sales staff or our engineers at Dingbo Power Generator Manufacturer. We will provide on-site guidance and on-site modification to meet the user's requirements.

In addition to the above reasons for the small generator set failing to reach 220V, there may also be the following phenomena:

1.Unbalanced three-phase load.

2.Slight short circuit in the generator winding.

3.Generator manufacturing defects (unequal number of turns in the three-phase windings).

4.Asymmetrical three-phase voltage, causing displacement of the neutral point potential of the generator set.

5.Excessive neutral current, which increases the operating temperature of the distribution transformer and, in severe cases, may burn out the transformer; it also causes some phase voltages to be high and others to be low.
