1000KW Cummins KTA38-G9 with Siemens Generator Set Technology

Dec. 21, 2023

As a foreign investor in the Chinese diesel engine industry, Cummins has 30 institutions in China, including 16 joint ventures and more than 10000 employees. Its cumulative investment in China exceeds 1 billion US dollars, including Dongfeng Cummins diesel generator sets and Chongqing Cummins diesel generator sets. Dongfeng Cummins produces B, C, and L series diesel engines, while Chongqing Cummins produces M, N, and K series diesel engines. This article introduces the technical parameters of the 1000KW Cummins KTA38-G9 with Siemens generator set.


cummins 1000kw diesel generator


Diesel generator set:

Rated power: 1000KW, standby power: 1250KVA

Rated frequency: 50Hz Rated voltage: 400/230V

Rated current: 1800A

Steady state voltage adjustment rate: ≤ ± 1%

Transient voltage adjustment rate: ≤+20 to -15%%

Voltage recovery time: ≤ 1.5S

Voltage fluctuation rate: ≤ 0.5%

Unit weight: 8200Kg

Unit size: 4800 × one thousand and eight hundred × 2300 (mm)


Diesel engine: Chongqing Cummins Engine Co., Ltd./KTA38-G9

1. Output power (KW): 1089;

2. Structural features: four stroke, turbocharged and intercooled;

3. Number of cylinder blocks: 12 cylinders;

4. Cylinder diameter/stroke (mm): 159/159;

5. Starting time (S): ≤ 5;

6. Lubrication method: pressure lubrication;

7. Cooling method: Equipped with a water tank fan for heat dissipation;

8. Speed regulation method: electronic speed regulation;

9. Rated speed (RPM): 1500;

10. Starting current (A): 600

11. Start method: 24VDC electric start;

12. Fuel consumption (g/kg/h): 196;

13. Smoke intensity (FSU): ≤ 1.5;

14. Exhaust temperature (℃): ≤ 650;

15. Total cylinder displacement (L): 37.8;

16. Diesel specification level: China 0 # light diesel

17. Compression ratio 13.9:1


Generator: CSIC Motor Technology Co., Ltd./1FC2451-4

1. Rated power: 1000;

2. Type: Brushless self-excited;

3. Insulation level: H level;

4. Protection level: IP22;

5. Structure: Integrated;

6. Overload capacity: Overload 10% - hour;

7. Short time current: 150% 10S

8. Electrical system: three-phase four wire, neutral grounded;

9. Power factor: 0.8 lagging


Jiangsu Dingbo Power Generation Equipment Co., Ltd. has been established for many years. In addition to strict requirements on the quality of diesel generator set products and after-sales service, it also has strict regulations on the plant environment, production equipment and supporting facilities, which reflects the strict style of Dingbo people. It is not only responsible for generator products, customers, but also employees, so that every employee of Dingbo Power generation equipment can work in a comfortable environment, Make it comfortable for every visiting customer to visit. Dingbo Power Group, relying on high-quality generators, generator sets, diesel generator, diesel generator sets, good services and the care of friends from all walks of life, carries forward the enterprise spirit of "pragmatic innovation, pioneering, unity and hard work, dare to be the first", and adheres to the enterprise style of "treating people with sincerity and heart to heart", has won the strong support of customers in the fields of post and telecommunications, finance, petrochemical, metallurgy, transportation, education, medical care, etc, Having a proud performance. Dingbo people are gradually moving towards economies of scale and entering the international market after joining the WTO with flexible sales strategies and relying on the company's advantages and strength. If you would like to get more information welcome to contact us via sales@dieselgeneratortech.com.
