Valve and Valve Tappet of Diesel Generator

When it comes to valves, people may not really understand them. Valves are important components of diesel generators. Although they are small, they play a crucial role. Therefore, Dingbo Diesel Generator Manufacturer would like to introduce the valve mechanism and the related functions of valve tappets of diesel generator sets.

1. Main Components of Diesel Generator Valve Mechanism

The valve mechanism can be divided into the valve group and the valve transmission group, which is classified according to functions. As a part of the valve mechanism, the valve group includes the following main components: valve guide, valve spring, valve, valve seat, valve spring seat and locking device, etc.

The valve operates under the conditions of high temperature, high mechanical load, and difficult cooling and lubrication. The valve head is also affected by gas pressure. The exhaust valve is also susceptible to the scouring of high-temperature exhaust gas and the corrosion of sulfides in the exhaust gas. Therefore, the valve is required to have sufficient strength, high temperature resistance, corrosion resistance and wear resistance.

During the compression and combustion processes, the valve must be tightly sealed without air leakage. Otherwise, the power of the diesel engine will decrease, because the final compression temperature and pressure are too low to ignite and start the diesel engine. When the valve operates under the condition of air leakage, high-temperature gas flows into the valve for a long time, causing the valve to overheat and burn.

2. What is the Diesel Generator Valve Tappet?

The function of the tappet is to transmit the thrust of the cam to the valve or push rod. The tappet is made of steel or cast iron. Generally, it is made into a hollow cylindrical shape, which not only reduces the weight but also obtains a larger pressure area to reduce the side pressure per unit area. The lower end of the push rod is located in the tappet hole.

In order to make the working surface of the tappet wear evenly, the center line of the tappet is usually offset 1-3mm from the symmetry line of the cam side. The base of the tappet is made into a sphere with a radius of 700-1000mm. When the cam rotates, the tappet is forced to rotate around its axis, so that the wear of the bottom and side of the tappet is relatively uniform.
