Parallel Conditions and Characteristics of Diesel Generator Sets

Diesel generator sets can operate either as a single unit, in parallel with multiple units, or be integrated into the power grid. The operation of a single unit is subject to many limitations. If its power is designed to meet the requirements of heavy - load conditions, the operating economy of the unit will decrease during light - load operation. Moreover, the standby unit needs to have the same capacity as the operating unit. By using multiple units in parallel operation or integrating them into the power grid, the power supply capacity can be expanded, and the reliability of power supply can be improved. Only one standby unit is required, which relatively reduces the capacity of the standby unit.

Four conditions must be met for parallel operation

①The terminal voltages should be equal.

② The frequencies should be equal.

③ The phases should be consistent.

④ The phase sequences should be consistent. At the same time, an operation protection device is required, which can automatically and reasonably distribute and adjust the active power and reactive power, making the frequency - regulation and voltage - regulation characteristic curves of the units tend to be similar.

Comparison between diesel generator sets and steam - turbine generator sets

Diesel generator sets have the following characteristics:

① They have a smaller volume, lighter weight and a simpler system per unit output. Generally, they are mostly supplied as a complete set. Therefore, the construction speed of diesel - engine power stations is fast.

② The thermal efficiency of diesel - engine power generation is relatively high, and the change in fuel consumption per unit output is not significant under partial - load or light - load conditions.

③ The starting, load - taking and stopping times of diesel generator sets are relatively short. They can be started at any time, making them more suitable as emergency power sources.

④ The operation and maintenance of diesel generator sets are simpler and more convenient compared with steam - turbine generator sets.

However, diesel generator sets also have some disadvantages:

① They can only use liquid fuel, and the fuel price is relatively high, so the cost of electricity is high.

② Diesel engines have greater wear, shorter service lives, more frequent overhauls, and their operation stability and overload capacity are worse than those of steam - powered devices.

③ There is significant vibration and noise during the operation of the unit, resulting in poor working conditions for workers.

④ A braking coil must be installed on the surface of the generator's magnetic poles to facilitate the starting and stopping of the unit.
