Minor Repair of Shangchai Diesel Generator Sets

During the use of Shangchai diesel generator sets, the main issue is the wear of internal moving parts of the diesel engine. The repair categories of diesel generator sets are mainly divided according to the wear laws of various parts of the diesel engine. Due to the differences in the structure, materials used and working conditions of various parts and assemblies, the time intervals for repair also vary. Therefore, there are three different levels of repair for diesel generator sets, namely minor repair, medium - repair and major repair. Now, let's introduce the basic content of the minor repair of diesel generator sets to users.

Basic Content of Minor Repair

1.Check and eliminate the three leakage phenomena (leakage of oil, water and gas) of the diesel engine. Tighten the loose external parts of the diesel generator set according to the specified torque.

2.Check various technical parameters of the fuel injection pump and injector. If they are incorrect, adjust them according to the specified data.

3.Adjust the valve clearance according to the technical requirements.

4.When replacing the piston rings, clean the carbon deposits in the cylinder head, the upper part of the cylinder liner and the piston ring grooves. When assembling the piston rings, also check the opening clearance of the ring ports.

5.Replace the lubricating oil and clean the oil pan.

6.Check all components of the starting system and clean and adjust them as required.

7.Replace some damaged parts and components. If necessary, check the internal moving parts of the diesel engine.

8.Check the contact situation between the working surface of the generator slip - ring and the brushes, and also check the spring force of the brush pressure springs.

9.Fill the generator bearings with grease according to the requirements of the technical manual.

Technical Requirements for Minor Repair

1.After grinding the intake and exhaust valves, thoroughly clean the grinding sand inside and outside the cylinder head. At the same time, conduct a leakage test on the valve sealing performance.

2.Adjust the various clearances of the piston rings according to the technical requirements. During installation, assemble them correctly according to the structure, characteristics and installation sequence of various rings, and do not install them reversely. The ring ports should be staggered from each other according to the technical requirements specified in the technical manual, and no overlapping is allowed.

3.The assembled bolts should not have phenomena such as bending, cracking and reverse - threading.

4.The inside of the oil pan, diesel tank, oil filter and diesel filter should be clean and free of impurities.

5.Adjust the oil pressure as required.

6.Check and adjust the pressure of the brush springs according to the technical requirements in the manual of the brush - type synchronous generator. The contact area between the brushes and the slip - ring should be more than 85%.

7.There should be no abnormal noise from the internal bearings of the generator.

8.The instruments and other components installed inside the generator control panel should not shake, and all kinds of screws should be tightened according to the technical requirements.

9.The insulation layers of the generator stator coil, rotor coil, excitation motor stator coil and excitation motor rotor coil should not fall off.

The purpose of the minor repair of Shangchai diesel generator sets is mainly to eliminate the common faults that occur during the use of the generator sets and keep them in good working condition. This minor - repair method mainly includes dealing with temporary faults that occur during operation, potential faults found during maintenance, and replacing individual severely worn parts.
