How to Measure Insulation Resistance with a Megohmmeter

1. Precautions for Using a Megohmmeter

① Handle the megohmmeter gently to avoid severe or prolonged vibration or flipping, which may damage the pointer shaft tip or bearings and reduce measurement sensitivity.

② When the pointer points to "0", do not forcefully crank the generator handle to prevent damage to internal coils.

③ After measurement, immediately discharge the tested object. Dingbo Power reminds: Do not touch the measured part or disconnect wires while the handle is still rotating or the object is not discharged to avoid electric shock.

④ Store the megohmmeter in a dry cabinet when not in use. Avoid extreme temperatures, humidity, dirt, or exposure to corrosive (acidic/alkaline) air/vapors, which may cause moisture absorption, mold growth, wire breakage, rust, or corrosion of internal coils, wiring, or parts.

2. Measurement Methods and Requirements

（1）Motor Status During Testing:

When measuring insulation resistance of motor windings, tests should be conducted under both actual cold and hot conditions. For inspection purposes, testing under actual cold conditions alone is acceptable.

（2）Measurement Procedures:

For motors with separate windings (e.g., stator windings, excitation windings of synchronous motors, or windings of reactors/current transformers in self-excited systems) where both terminals are exposed outside the motor housing: Measure insulation resistance of each winding to the housing and between windings. Non-tested windings must be reliably connected to the housing during testing.

For internally connected windings (e.g., three-phase windings connected in Y or Δ): Only measure insulation resistance from windings to the housing.

For hand-cranked megohmmeters: Maintain a rotation speed of approximately 120 r/min. Readings should be taken after the pointer stabilizes.

After measurement: Discharge the tested winding to the ground before disconnecting the test leads.
