Generator Control Box

The control box is generally a closed metal structure made of high-quality steel plates through stamping and welding. It can be used for the control, measurement, protection, power transmission and distribution of mobile or small-capacity generators. Usually, the control box is installed on the back of the generator via shock absorbers, forming an integrated unit with the generator.

The panel of the generator set control box is equipped with an ammeter, voltage changeover switch, output indicator, voltmeter, frequency meter, power meter, automatic air switch, AC and DC sockets, etc., which can monitor the operating status of the generator set. A field rheostat is also installed on the side of the control box for adjusting the voltage or reactive power of the generator set. The number of instruments set on the control box panel varies depending on the capacity of the generator set and user requirements. Different excitation methods of generator sets result in different devices used for adjusting the generator voltage. In addition to the above-mentioned field rheostat, some use reactors, and those with high voltage regulation rate use automatic excitation regulators.

Some control boxes are equipped with a differential adjustment device, light synchronization indicator, oil pressure gauge, battery charging ammeter, electric switch, start button, synchronization voltmeter, water temperature gauge, oil temperature gauge, etc., to meet the parallel operation of small three-phase generator sets and monitor the operating conditions of the diesel engine.

The circuits of small three-phase generator set control boxes produced by different manufacturers are not completely identical but generally similar. They can be summarized into the following two types:

1.Stand-alone Operation Control Box

1.1 XFK-13 Type Control Box

1.2 XYF-51-75 (TH) Type Control Box

1.3 XFK-7A Type Control Box

2.Parallel Operation Control Box Circuit

2.1 XYF-52-50 (TH) Type Control Box

2.2 XYF-51-75 (TH) Type Control Box

2.3 XFK-7A Type Control Box

To better use the diesel generator set, we need to repair and maintain the generator control box during its use. For novice users, Dingbo Diesel Generator Manufacturer can provide you with several protection suggestions:

When using the control box, it should be used in a clean, dry and well-ventilated environment to prevent dust, water droplets and other debris from entering the box. No matter what kind of equipment it is, regular inspection and maintenance are required, and the control box also needs regular maintenance to ensure good contact. If it is not used for a long time, before use, it is necessary to test the insulation of relevant components, and if moisture is found, it can be used only after drying. In case of an unexpected trip, the fault cause must be found out before closing the control box again.
