Gasoline Generator Plug Wiring Guide

Gasoline generator sets use gasoline as fuel to convert other forms of energy into electrical energy. They are widely used in industrial and agricultural production, national defense, science and technology, and daily life due to their advantages of low fuel consumption, easy maintenance and operation, and high economic applicability.

The installation of plugs in generator equipment is a key link to ensure the operation of the generator. Many users will ignore this detail, so Dingbo Power Generator Manufacturer will suggest in after-sales service that users buy a socket to replace the ordinary plug and connect it to the generator-specific plug after purchasing the generator.

Gasoline generators have one or two sockets for power transmission. The plugs of gasoline/diesel generators are completely different from ordinary household plugs, and the generator plugs produced by each manufacturer are also different. This causes some customers to not know how to wire and connect ordinary sockets to the generator after purchasing the generator.

Now let's introduce the wiring method of gasoline/diesel generator plugs:

First, we first use a blade to pry open the cover on the plug that comes with the generator, then remove the cover, and then you will see three pillars inside the generator-specific plug. Among them, two pillars are of the same length, and one pillar is longer than the other two. Then we connect the wires to the two pillars of the same length. Because the socket has two wires, one neutral wire and one live wire, at this time we only need to replace the plug of the ordinary socket with the special plug on our generator. At this time, we just need to connect the wire on the purchased socket to the generator-specific plug. Connect the two wires to the two pillars marked with red circles respectively.

Secondly, use the two screws on the pillars to fix the wiring, which can connect the generator's power to the mains. If the wire of the generator's plug is connected to the mains, there is no need to purchase a new plug at this time.

For generators, if the generator plug cannot be wired in a professional manner, it will not meet the generator's current capacity requirements. On the other hand, unqualified generator plugs are prone to burning and more likely to cause major accidents such as fires. Therefore, the installation of generator plugs must be carried out under the supervision of professionals. Although the safety requirements for small generator equipment are lower than those for large generator sets, the safe installation of generator plugs cannot be simply ignored, as it can directly affect the operating efficiency and service life of the generator.
