Diesel Generator Water Jacket Heater

Many diesel generator sets are now equipped with automatic configurations, which means the unit can start automatically when the mains power fails and stop automatically when the mains power is restored. Control panels with a preheating button can control the engine to start heating for preheating purposes.

In winter when the temperature is low, it is difficult to start the generator set. Because the temperature of the antifreeze in the water tank and the oil in the engine block is low, the temperature of the air sucked into the cylinder is relatively low, and it is difficult to reach the diesel combustion temperature after the piston compresses the gas, so the generator set cannot be started. One of the solutions to this problem is that the generator manufacturer, Dingbo Power, recommends installing a generator set water jacket heater, which is a device that can preheat the temperature in the engine block and water tank. The water jacket heater can not only enable the diesel generator set to start quickly in cold weather conditions, but also greatly reduce the damage to the unit caused by low-temperature start-up.

The diesel generator set water jacket heater is made of high-quality stainless steel and is equipped with a constant temperature control device. It has the characteristics of beautiful appearance, long service life, corrosion resistance, etc. It is suitable for Cummins, Yuchai, Perkins, Mercedes-Benz, Caterpillar, Mitsubishi, Volvo, Shangchai, Weichai and other engines for preheating start-up and warm-up antifreeze.

Main Technical Parameters

Voltage: AC 48V, 110V, 220V; DC 12V, 24V, 48V

Insulation Resistance: ≥10MΩ

Dielectric Strength: 1500V/1min (normal state)

Temperature Control Range: 25℃-85℃ (adjustable)

It is allowed to enter full load operation only when the outlet water temperature of the diesel generator is higher than 75℃, the oil temperature is higher than 50℃, and the oil pressure is higher than 0.25MPa 2.5kgf/cm².
