Development Trend and Operational Monitoring of Diesel Generator Sets

Diesel generator sets can be used as main generators or backup power sources, playing an indispensable role in the production and daily life of enterprises and institutions in various fields.

With the continuous development of science and technology, intelligence, automation, and cloud services have become a development trend for everything from large equipment to small mobile phones. The development of diesel generators will also conform to this trend, moving towards intelligent operation, making future diesel generators more intelligent and easier to operate.

In terms of intelligence, diesel generator sets are mainly manifested in various safety protection and fault monitoring and diagnosis measures, such as temperature monitoring, generator overload and overheating protection, vibration signal monitoring and fault abnormal diagnosis, automatic compensation for axial position changes, automatic control, and damage signal monitoring. For example, domestic diesel generator sets are equipped with diagnostic modules, through which maintenance personnel can read data via infrared interfaces, identify overloads, and count working life.

At present, maintenance personnel of diesel generator sets identify the operating status of diesel generator sets by checking various conditions on the unit's instruments.

(1)Ammeter: Observe whether the ammeter pointer indicates normally. Switch the current changeover switch to measure the phase current values between each phase sequence. Under normal circumstances, the difference between each phase sequence should not exceed 10%.

(2)Voltmeter: Observe whether the voltage value indicated by the voltmeter pointer is normal.

(3) Charging meter: Observe whether the charging meter pointer is in the (+) direction. If the pointer deviates to the (-) direction, it indicates no charging.

(3)Oil pressure gauge: Observe whether the oil pressure indicated by the oil pressure gauge is within the normal range.

(4)Water temperature gauge: Observe whether the water temperature gauge indicates within the normal range (65~93℃). If the pointer does not move or is higher than 93℃, it is abnormal.

(5)Tachometer: Observe whether the engine speed is appropriate. Under normal circumstances, if the frequency is 60Hz, the speed is 1800r/min.

(6)Sound and vibration: Listen carefully to the running sound. Under normal circumstances, there should be no abnormal sound or vibration.

The automatic control system of Dingbo automatic generator sets can accurately and agilely adjust the operation of diesel generator sets. When the generator set is in an abnormal state, the automatic control system can make normal judgments and real-time handle, issue corresponding alarm signals and emergency shutdowns to prevent damage to the generator set. Moreover, improving the power quality target and operational economy makes various electrical equipment work in a good working state, which is beneficial both to the automatic generator set itself and the users.

Guangxi Dingbo Generator Set Manufacturing Co.,Ltd. has advanced testing equipment, modern production technology, professional manufacturing technology, perfect quality management system, and strong technical research and development capabilities. It can provide 3KW～2500KW various specifications of ordinary, automatic, four protection, automatic switching, low noise and mobile generator sets, high quality and low energy consumption to meet the diverse power needs of customers, and can also meet users with different voltages and different frequencies. It is required to create a parallel power supply system for multiple units. If you are interested in our product or any question on generator, welcome to send email to [email protected].
