Common Types of Generator Sets

Currently, manufacturers produce a wide variety of generator sets with differing uses and specifications, so extra care is required when purchasing. Many customers have made mistakes due to insufficient prior understanding, which is clearly undesirable for both parties. Therefore, this article introduces common types of generator sets, hoping to be helpful.

1. Plateau Type: By optimizing the engine and generator's plateau power output, the system incorporates a high-temperature radiator, an independent (water-warmed) liquid fuel heater system, high-performance large-capacity maintenance-free batteries, and high-quality electrical components. It is suitable for altitudes of 3,000-5,000 meters and ambient temperatures ranging from -40°C to 50°C, having been successfully deployed in major national projects such as the Qinghai-Tibet Railway and the Lhasa-Nyingchi Railway.

2. High-voltage type: Composed of a diesel engine, generator, common base, high-voltage switchgear, PT cabinet, control panel, low-voltage power box, etc. The main voltage levels include: 6kV, 6.3kV, 6.6kV, 10kV, 10.5kV, 11kV, etc. The frequency options are 50 or 60Hz. The power output of a single high-voltage unit is generally above 1000kW, and multiple high-voltage generator sets can be connected in parallel for operation.

3. Mobile power stations: Primarily used for field operations and mobile lighting, including hand-pushed, three-wheeled, four-wheeled, trailer-mounted, truck-mounted, container-mounted, and power engineering vehicles.

4. Silent Power Station: A noise-reduced power station designed to meet urban environmental protection requirements, capable of lowering noise levels to around 70 dB(A), suitable for urban and mobile power supply operations.

5. 190 Series: With mature technology and stable performance, this series has long supplied equipment to China's petroleum industry, particularly suited for field operations and harsh environments. The power range spans 400-2000 kW, making it a product of domestically produced high-power diesel engines.

6. Fire Power Supply: In the event of a fire or similar incident, when the mains power is cut off, the generator set can quickly become the power source for firefighting equipment, minimizing casualties and property damage while safeguarding public safety and interests.

Guangxi Dingbo Generator Set Manufacturing Co.,Ltd. was founded in 1974 and is one of the earliest manufacturers of generators and diesel generator sets in China. The company has a registered capital of 218.88 million yuan. The company covers an area of 86,000 square meters and a building area of 55,000 square meters. There are more than 660 employees, including 456 professional technicians and 106 senior technicians. It has 46 sales and service outlets nationwide. The main products are diesel engines, generator sets, and diesel generators, providing users with a one-stop service of design, supply, debugging and maintenance at any time. Dingbo has always insisted on using first-class talents, building first-class enterprises, manufacturing first-class products, creating first-class services, and making every effort to build a first-class domestic enterprise. If any question please feel free to visit our website https://www.dieselgeneratortech.com/ or send email to [email protected].
