Common Misinstalled Parts in Diesel Engine Maintenance

When assembling engine parts, single-sided components are relatively easy to install. However, for parts requiring double-sided installation—especially non-positioned ones—carelessness may lead to reversed or incorrect assembly. Misinstallation can damage parts or even the generator set. While many manufacturers produce "foolproof" parts that prevent reverse installation, caution is still necessary during repairs or replacements. Dingbo Power, a generator manufacturer, outlines the most easily misinstalled/reversed parts in diesel engine maintenance:

Cylinder Head Gasket

During assembly, the crimped side must face the cylinder head. Reversal causes early air leakage, cylinder head gasket burnout, and reduced service life.

Piston Groove

The horseshoe-shaped groove or peach-shaped tip on the piston top must face upward. Reversal impairs fuel-air mixing; unburned fuel fails to form secondary eddy current (secondary eddy current: secondary vortex), leading to incomplete combustion, preventing the diesel generator from starting or operating normally.

Connecting Rod and Piston

When assembling the connecting rod and piston: The oil hole in the small end of the connecting rod must align upward with the piston’s horseshoe groove or peach-shaped tip. Misalignment causes insufficient lubrication between the small-end bushing and piston pin, resulting in dry friction and wear.

Connecting Rod Bearings

Newly replaced upper and lower connecting rod bearings are interchangeable. However, used bearings must be reinstalled in their original positions; swapping them disrupts the journal-bearing fit.

Connecting Rod Cap and Rod

The connecting rod big end and cap have alignment marks, which must be positioned on the same side during assembly. Misalignment compromises the original machining accuracy of the rod bore and disrupts proper bearing-journal contact.

Injector Pressure Plate

The injector pressure plate has a flat side and an arc side. The arc side must face the injector body to ensure centering during compression; otherwise, the mounting bore may leak.

Oil Seals

All oil seals (e.g., crankshaft, starter shaft seals) must have their self-tensioning spring side facing the engine interior. Reversal causes crankcase leaks and oil seepage.

Plunger Sleeve

In the fuel injection pump, the plunger’s crescent-shaped hole must align with the pump housing’s plunger sleeve positioning screw hole. This ensures the positioning screw engages the crescent slot, preventing plunger rotation. Reversing (rotating 180°) may block the oil return hole, causing uncontrolled fuel supply and engine overspeed ("runaway").

Small Washers on Fuel Injection Pump

Two distinct washers are used: A copper washer for the plunger sleeve positioning screw and a spring washer for the tappet guide screw. Interchanging them causes diesel leakage into the oil pan or externally.

Breather on Gear Chamber Cover

When installing the breather’s central reed assembly, the reed must face outward to ensure one-way exhalation (no inhalation).
