Common Features of Diesel Generator Set Controllers

As users' requirements for diesel generator sets continue to rise and diesel generator manufacturers continuously upgrade their products, generator set control modules are widely used due to their excellent technical performance, such as domestic ones like Kaixun and Zhongzhi, and imported ones like Deep Sea and ComAp. The use of both domestic and imported diesel generator set controllers not only provides users with a simple and convenient way but also enhances the humanization level of the units.

Although there are various types of diesel generator set controllers, whether domestic or imported, there may be some differences in certain aspects, their functions have many similarities. Then what are they specifically? Dingbo Diesel Generator Manufacturer will list a few for you.

1.Diesel generator set controllers generally feature a backlit LCD display that can show in multiple languages, such as Simplified Chinese, English, Spanish, and Russian. The touch buttons are simple and convenient to operate and have good wear resistance.

2.They are equipped with communication interfaces, enabling "three remote" (remote monitoring, remote control, remote signaling) functions, and have strong adaptability to high and low temperature environments.

3.They are suitable for three-phase four-wire, three-phase three-wire, single-phase two-wire, two-phase three-wire power supplies, and 50 Hz/60 Hz systems, etc.

4.They collect and display power supply/generator three-phase voltage, three-phase current, frequency, and power parameters; the power supply has overvoltage, undervoltage, and phase loss protection functions; the generator has overvoltage, undervoltage, underfrequency, and overcurrent protection functions. They accurately collect various engine parameters, can directly use various temperature, pressure, and oil level sensors, and parameters can be customized.

5.They realize functions such as automatic start/stop of diesel generator sets, switch switching, fault display and protection. The control panel has functions such as power-on shutdown, idle speed control, preheating control, and speed up/down control.

6.They have a wide range power supply of 8-35VDC, which can adapt to different starting battery voltage environments.

7.The controllers adopt a modular structure design with flame-retardantshell, metal card fixing, pluggable terminal blocks, and embedded installation method, featuring compact structure and convenient installation. Due to these characteristics, they can be widely used in various types of generator set automation systems.
