Air Filter Maintenance Plan for Diesel Generators

The air filter assembly consists of an air filter element, filter cover, and housing. The quality of the air filter plays a crucial role in the air filter assembly. The maintenance plan for diesel generator air filters should include the following contents: 1. Maintenance items and contents; 2. Maintenance time; 3. Estimated cost; 4. Spare parts plan.

Air Filter Indicator

Air filter maintenance cycle: Every 50 operating hours or every quarter, whichever comes first.

WARNING: Never start or run the diesel engine without the air filter. Otherwise, it may easily cause early wear of the diesel engine.

Method for Removing Air Filter (by Diesel Generator Manufacturer)

Loosen the iron ring, remove the dust collector and filter element, and carefully clean the filter element from top to bottom. If the filter element is not too dirty, it can be directly blown clean with compressed air, but attention should be paid that the air pressure should not be too high and the nozzle should not be too close to the filter element. If the filter element is too dirty, use a special cleaning fluid purchased from the diesel generator manufacturer for cleaning, then dry it with an electric hair dryer, taking care not to overheat. After cleaning, an inspection should be carried out. The inspection method is to use a light bulb to illuminate from the inside out and observe the outside of the filter element. If light spots are found, it indicates that the filter element has perforated, and the filter element of the same model should be replaced at this time. If no light spots appear, it indicates that the filter element is not perforated, and the air filter should be carefully installed at this time.

When installing the filter element, ensure that the filter element sits on the gasket at the outlet end of the air filter. The air filter resistance should be checked under the diesel engine's rated operating conditions. If the air filter is equipped with a maintenance indicator, check it. If it shows red, it indicates that the air filter has reached the service limit, and the air filter element should be cleaned or replaced immediately. After processing, press the button switch on the end of the maintenance indicator to reset it.
