Model No.: DB-WP-200
Engine Power: 15KW
Maximum Revolution: 3600RPM
Maximum Head Lift: 20m
Maximum Flow Rate: 240m³/h
Maximum Suction Lift: 2m
Fuel Tank capacity: 30L
For more types, please contact us.
Features:
1. The intelligent single-stage centrifugal self-priming pump is manufactured from high-strength, corrosion-resistant materials. This pump offers high head, large flow, and reliable operation.
2. Super-large inlet and outlet sizes ensure rapid suction and high flow.
3. A high-capacity fuel tank provides prolonged runtime and increased efficiency.
4. Brake-equipped universal wheels enable easy, effort-saving mobility.
Product's Technical Parameters：
| Item | Water Pump with Gasoline Engine |
| Model No. | DB-WP-200 |
| Pump Type | Single-stage centrifugal drainage pump and four-stroke two-cylinder air-cooled engine |
| Engine Model No. | DH740 |
| Engine Power | 15KW |
| Maximum Revolution | 3600RPM |
| Controller | 2.8-inch/ 240*128 LCD HD-display screen |
| Max Head Lift | 20m |
| Maximum Flow Rate | 240m³/h |
| Maximum Suction Lift | 2m |
| Self-Priming Time | 180S |
| Outlet Diameter | 200mm |
| Inlet Diameter | 200mm |
| Display System | LCD HD-display screen |
| Fuel Tank capacity | 30L |
| Engine Type | 4-stroke, air-cooled |
| Starting Battery | Maintenance-free Battery |
| Water Pump Configuration: | 1 Pump Unit, 1 Bottle of Engine Oil, 1 Tool Set, 1 Quality Certificate, 1 Packing Case |
| Dimensions(L*W*H) | 1152×732×1002mm |
| Weight | 165kg |
Dingbo Power DB-WP-200 8-Inch gasoline engine water pump is with a flow capacity up to 240m³/h and a pumping head up to 20m, making it ideal for jobsites or farm/agricultural applications.
